Sphere Automated Satellite System

1300 781 229

or make 4 interest-free payments of fortnightly with Afterpay More info

SKU:
900-06002
Quantity:

Product Description

Moving with the times, the Sphere Automated Satellite System (SASS) is innovative and technologically advanced. It has been designed to locate and lock onto satellites quickly (in particular, the C1/D3 satellites which cover the majority of Australia).

It is compatible with Direct Broadcast Satellites (DBS) which broadcast audio, video and data from satellites about 35,406km away! To ensure the best signal is received from DBS, the SASS must have a clear view of the satellite i.e. make sure there are no trees or heavy cloud in the signal pathway. It also has a built in Digital Broadcast Receiver.

SASS comprises of two main components: the dish (which houses the positioning mechanism and twin LNBs) and the indoor unit (IDU which is the systems user interface and allows the user to control/access SASS). SASS comes with a pre-drilled mounting base plate, making it easy to install and offers better weight distribution across the RV rooftop.

Product Description

The Sphere SAA-850 RV Satellite Antenna with auto skew twin LNB is innovative and a technologically advanced satellite positioner system. The antenna has a unique combination of state-of-the art components with the most sophisticated satellite acquisition and tracking programs to locate and lock onto the OPTUS C1/D3 satellite in Australia.

Features:

  • Auto Skew
  • Twin LNB
  • Fast satellite acquisition of the OPTUS C1/D3 (that use a 10.700GHz L.O)
  • Capable of high definition receiving



Specifications

  • Antenna Unit:

    The antenna unit houses the antenna positioning mechanism, LNB (low noise block), and control elements within the antenna. Weather tight connectors join the power, signal and control cabling from the antenna IDU unit.

    Indoor Unit: (IDU)

    The IDU is the system's user interface, providing access to the system and its functions through an LCD display power and two control buttons. IDU provides the power to the antenna as well as receives the satellite signal from the antenna unit.

    (Satellite receiver required)

    • Power: 12V
    • Frequency: 10.7GHz (twin LNB)
    • Closed Height: 200mm
    • Size of Mounting Base Plate (mm): 700L x 400W
    • 450mm – surrounding items must not be taller than 190mm
    • 200mm – surrounding items must not be taller than 70mm
    • Installed Weight: 19kg (includes cables and IDU), 16kg (dish and base plate only)
    • Recommended Clearance (from centre of rotating head): 600mm – surrounding items such as air condtitioners or hatches must not be taller than 260mm. If surrounding items are taller than 260mm, more clearance is  needed.



*Postage may be a higher cost to some remote areas and if the the item is over 2 meters in length or a heavy product. You will be contacted personally with a price quote if you fall into this category.

** Product images are for illustrative purposes only.

*** Prices and availability of products and services are subject to change without notice. Errors will be corrected where discovered, Oztackle reserves the right to revoke any stated offer and to correct any errors, inaccuracies or omissions including after an order has been submitted and whether or not the order has been confirmed and your credit card charged
